TEC Digital Stabiliser (2000A - 2000VA)

Stabilizer Features

Wider input voltage (91V - 279V AC), Stable power output, Analogue, Time delay push botton, High Voltage protection, Overload protection, Short circuit protection, Microprocessor controlled, Single phase

Capacity

2000VA

Input Frequency

50HZ

Standard

CE; SONCAP

Wider Input Voltage Range (91 - 279V)

Yes

Powerful 100% loading capacity when the input voltage at 160-260Vac

Yes

Circuit Board

The high quality CPU chip which was used in the mather board to ensure the circuit board working fast and accuracy

Cover Type

thicker metal cover and frame was used for the machine protection

Resetable Circuit Breaker

Yes

Transformer high temperture protector was used to cut off the output when overloading

Yes

high voltage protection, overloading protection, short circuit protection etc which could safe guard the stabilizer

Yes

High quality EI transformer for the power below 2KVA ,which were used the imported first hand silican steel sheet

Yes

High quality C.R.G.O transformer for the power above 5KVA ,Which used the high temperature insulating panting technology for the colings and high effiency core which avoild the transformer power consumption

No

Famous CHNT brand name air swich was used for the 5KVA &8KVA

No

Rate of Correction

3mili sec

Display

Digital

Dimension

Height

240.0

Depth

180.0

Width

150.0

Voltage

Output

180-250V

Input

91-279V

Protection

High Voltage

Yes

High Temperature

Yes

Short Circuit

Yes
